BCS619A Diesel Injection Pump Tesing Machine 12 Cylinder Conventional EPS619 Test Bench
Details
The BCS619A Diesel Injection Pump Test Bench is a high-performance diagnostic tool designed for professional fuel system service. It supports the measurement of each cylinder's delivery at any speed and features specialized functions for testing distributor pumps and VE pumps. With power options up to 22KW and a 12-cylinder capacity, it provides a stable and accurate environment for calibrating injection pumps.
BCS619A Diesel Injection Pump Tesing Machine 12 Cylinder Conventional EPS619 Test Bench Advantage
Multi-Brand Compatibility: Efficiently tests and adjusts a wide range of diesel injection pumps and distributor pumps.
Precision Testing: Accurate measurement of cylinder oil delivery, interval angles, and internal pump pressure.
Comprehensive Functionality: Includes specialized testing for supercharging, compensatory devices, and electromagnetic valves (12V/24V).
Durable Construction: Housed in robust plywood case packaging for safe global shipping.
Reliable Support: Comes with a one-year warranty and lifetime technical support from Beacon Machine.
parameter
| Item | Parameter |
|---|---|
| Model | BCS619A |
| Voltage | 380/220v 3-phase |
| Power Output | 11KW/15KW/18.5kw/22kw |
| Speed Range (RPM) | 0~4000 |
| Number of Cylinders | 12 |
| Volume of Test Oil Tank | 40L |
| Machine Dimension | 190*98*167 cm |
| DC Power Supply | 12V/24V |
